2021-2023 Ford F-150 5.0L With Power Onboard Gen 6 3.0L Whipple Supercharger Stage 1 Kit

2021-2023 FORD F-150 5.0L WITH POWER ONBOARD
GEN 6 3.0L WHIPPLE SUPERCHARGER STAGE 1 KIT

If you want a premium bolt-on supercharger system for your 2021-2023 Ford F-150 5.0L equipped with Power Onboard, the Whipple Gen 6 3.0L Stage 1 kit delivers the kind of power, drivability, and engineering refinement that has made Whipple the leader in twin-screw supercharging. Built for 91 octane or better and real-world truck use, this system delivers up to 725 horsepower and 650 lb-ft of torque with the instant boost, broad torque, and everyday usability F-150 owners expect.

Since 1987, Whipple Superchargers has led the industry in twin-screw supercharging technology. As the first to introduce positive displacement superchargers to fuel-injected platforms, Whipple has built a reputation for bolt-on horsepower, OEM-caliber reliability, and industry-leading thermal efficiency. Designed, manufactured, and assembled in the USA at Whipple Superchargers' facility in Fresno, California, this Stage 1 system reflects decades of Whipple development across both OEM and high-performance applications.

For 2021-2023, Whipple developed the updated Gen 6 design to push the F-150 5.0L platform even further. At the center of the package is the front-feed Gen 6 W185AX 3.0L / 3000cc Whipple twin-screw supercharger, featuring an all-new housing, inlet, and pulley design for improved efficiency and airflow capacity. The Gen 6 also features Whipple's proven 3x4 rotor combination, oversized Crusher™ 150mm inlet, and inverted layout that places the supercharger in the engine valley for a clean, integrated installation.

This version of the Stage 1 kit is designed specifically for 2021-2023 F-150 5.0L dual alternator Power Onboard applications. It retains the stock throttle body path while delivering the same premium Whipple airflow and thermal control package, giving Power Onboard owners a clean bolt-on solution that maintains compatibility with the factory dual alternator configuration.

Thermal control is a major part of the Whipple advantage. The patented dual-pass, dual-core intercooler system forces air through each intercooler core twice for outstanding cooling efficiency, while the massive heat exchanger and high-flow intercooler pump help maintain stable air charge temperatures in demanding conditions. The inverted design also allows for a massive air-to-water intercooler package, added plenum volume below the intercooler core, and improved use of the available surface area for lower pressure drop and repeatable performance.

Whipple's calibration strategy is another major differentiator. Designed specifically for the latest F-150 platform, the system is built to work with the new OTA-style PCM and Ford's advanced 10-speed transmission strategy. The included Whipple Tomahawk flash tool supports calibration loading, code reading and clearing, and wheel, tire, and axle ratio adjustments, giving customers a straightforward interface while helping retain factory drive modes such as Off Road, Tow, Eco, and Sport.

Just as important, the Stage 1 system is designed to install with minimal tools required and no cutting or grinding. It fits under the factory hood with no modifications and includes the major parts and hardware needed for installation. The result is a clean, premium bolt-on package that delivers instant boost at the touch of the throttle, strong off-idle response, flat torque delivery, and the kind of refinement that has long defined Whipple Superchargers systems.

KEY FEATURES

• 50-state legal, CARB EO D-231-144
• Up to 725 HP and 650 lb-ft of torque on 91 octane or better*
• Fits 2021-2023 Ford F-150 5.0L dual alternator Power Onboard applications
• Front-feed Gen 6 W185AX 3.0L / 3000cc Whipple twin-screw supercharger system
• Gen 6 supercharger with updated housing, inlet, and pulley design
• Whipple 3x4 rotor combination for increased RPM capacity and airflow
• Oversized Crusher™ 150mm inlet for maximum airflow capacity and minimal rotor cavitation
• Retains the stock throttle body in Stage 1 configuration
• Fully sealed, inverted design for clean fitment and factory-style appearance
• Patented dual-pass, dual-core intercooler design
• Massive air-to-water intercooler package for improved thermal control
• Extra plenum volume below intercooler core for reduced pressure drop
• High-flow intercooler pump
• Largest dual-pass heat exchanger on the market as standard
• Massive oversized intercooled air-bypass system for drivability and efficiency
• Designed to work with the new OTA-style PCM
• Designed for Ford 10-speed transmission strategy
• Factory drive modes such as Off Road, Tow, Eco, and Sport are retained
• Included Whipple Tomahawk flash tool
• Tomahawk supports calibration loading
• Tomahawk allows wheel, tire, and axle changes
• No other upgrades required for Stage 1 installation
• Fits under factory hood with no modifications
• Kits come complete with all necessary parts and hardware for installation
• Plug-and-play wiring with male and female connections
• Proven 6-rib belt system and adjustable idler system
• OEM quick-connect fittings for easy installation
• Instant boost at the touch of the throttle
• Flat torque curve for incredible acceleration
• 3 minute pulley changes
• Easy belt changes
• Lightweight pocketed 6061 T6 billet aluminum SC pulley
• Designed, manufactured, and assembled in the USA at Whipple Superchargers' facility in Fresno, California

*Power numbers are quoted with 91 octane or better under optimal conditions. Actual results may vary depending on fuel quality, altitude, vehicle configuration, and testing procedures.
